| Processing Parameters | Maximum workpiece length | mm | 300 | |
| Maximum turning diameter | mm | 400（Swing Diameter 450） | ||
| Maximum turning allowance | mm | One side 5mm diameter 100 | ||
| Main Axis | Range of Spindle Speed | mm | 3000 RPM | |
| Number of spindle speeds | mm | Stepless | ||
| Chuck | Hydraulic chuck | A2-6 | Standard chuck | |
| Hydraulic cylinder | A2-6 | L-125 | ||
| Main motor power | kW | 7.5/11(Servo) | ||
| Feed Motion | Z Maximum shaft travel | mm | 610 | |
| X Maximum axis travel | mm | 250 | ||
| Fast moving speed X/Z | m/min | 10 | ||
| Minimum input unit X/Z | mm | 0.001 | ||
| Driving X/Z | N.m | 10/15 | ||
| Turret | Cutter Turret Station | 8/12 | ||
| Turning tool body size | mm | 25×25 | ||
| Turret switch tool time | s | 1.5 | ||
| Machine Dimension (L×W×H) | mm | 2300×1600×2350 | ||
| Weight | Kg | 7000 | ||
