● Apply：Large shaft parts
● Lathe Bed：Heavy-duty load-bearing performance of the integral casting flat bed structure, the left and right sides of the bed with stacked wide thick body type cross slide structure, the spindle box on the slide to realize the longitudinal and transverse movement.
● Clamp：Double V-type hydraulic auto-centering upper and lower clamping type two fixtures, wide fixture support plate mounted on the wide guideway surface of the bed.
● Control System：CNC digital control, all machine movements and auxiliary actions are CNC programmed.
● Advantage：Easy operation, convenient adjustment, stable and reliable machining accuracy, high machining efficiency, etc.
● Machining Functions:
Standard Features：Milling end faces，drilling center holes.
● Optional Features
1、 Milling end face, drilling and tapping, turning of the outer circles, chamfering, etc.
2、 End face milling, boring, chamfering, etc.
3、 End face milling, hole tapping center, turning of the outer circles, chamfering, etc.
| Technical parameters | Unit | KPD400-4000 | Remark |
| Machining diameter range | mm | Customize according to requirements | There are a variety of specifications models can be processed φ0.5 m length of 10 meters or less according to the actual product customization. |
| Machining length range | mm | Customize according to requirements | |
| Special function milling, drilling, tapping | mm | M3-30 | Optional power up to M35 |
| Maximum one-sided milling | mm | 10 | |
| Machine control mode | Beijing KND / Juxin System / Guangshu / Siemens / Fanuc / other CNC systems | ||
|
Machine tool external dimensions |
m |
9*2.6*2.5 |
|
| Machine tool total power | Kw | 65 | |
|
Machine tool weight |
T |
≈22 |
|
